New Coach IRIZAR I8 15.37

CONTACT: show contacts

IRIZAR i8 INTEGRAL

1. General data / dimensions

Coach: Irizar

Model: i8

Type: integral

Length: 15 m

Height: 3.98 m

Width: 2.55m

Number of axles: 3

Number of seats: 65 + 1 + 1

GVW: 25,000kg

Door arrangement: 1-1-0

Electrically operated door with anti-trap protection and brake lock when open.

Electrically heated multilayer windscreen.

Double glazed side windows factory heavily tinted VG7

2. Suspension system

Front axle: on independent air suspension

Rear axle: on independent air suspension

Suspension: with self-leveling system, vehicle height control from the driver's cockpit and independent tilting of the vehicle to the right

3. Appearance / colors / materials

Color white RAL9003

Exterior mirrors, bumpers, body color radiator grille

Alcoa Black alloy wheels

Photo i8 slid out and folded back.

4. Engine / cooling system / fuel system

Engine: DAF MX 13 355 kW (480 HP) 12.9 l EURO 6

Fuel tank capacity: 670L

Engine compartment with additional soundproofing insulation

The bonnet is lockable

Diagnostic connector for diagnosing the engine from an external diagnostic device

5. Steering, braking and chassis, gearbox

Multifunctional leather steering wheel adjustable in two planes

Hydraulic power steering

Ventilated front and rear disc brakes.

Anti-lock braking system.

Anti-slip system when starting ASR.

ESC stabilization system.

Electronic braking force distribution EMCDDA

Additional retarder brake integrated into the gearbox.

A stop brake that prevents starting when the door is open

ZF 12-speed automatic gearbox - Traxon

TPMS - wheel pressure and temperature control system.

LDWS - lane assistant.

AEBS - automatic emergency braking system (anti-collision radar)

ACC - active cruise control

PCC - adaptive cruise control

Built-in wheel arches - protection against snow and mud

6. Vehicle lights / interior lighting / additional signaling

LED headlights integrated with LED daytime running lights.

The stop light is activated when the additional Retarder brake is applied

Fog lights - LED

"Stop" buttons signaling stopping on demand / notification to the driver

Engine compartment lighting

Backlight on bus entrance steps

Indoor and night lighting controlled from the driver's cockpit

Lighting of the main luggage space

Pneumatic and electric horn

7. Equipment

Two-zone air conditioning controlled electronically.

47KW air conditioning compressor

Reversing camera.

Rear entrance camera

GPS navigation

Touch MMI monitor

Central vacuum cleaner

Rain sensor that automatically activates the wipers

Dusk sensor that automatically turns on the lights

Exterior mirrors heated and electrically operated

Interior mirror

The left driver's window is heated and electrically opened

Cruise control with a speed limiting system for steep descents

Maximum speed locking system programmable in the steering wheel.

Outside temperature indicator in dashboard with temperature signaling 4oC

Two switches for the electrical system (main disconnecting the battery, and the second leaving the Webasto power supply, tachograph and car alarm)

Additional heating independent of Spheros engine operation with the possibility of programming 7 days ahead.

Boot lid pneumatically opened upwards with control from the driver's cockpit.

Vinyl windshield cover

Bosch Professional and DVD audio system

Three passenger monitors (first 22 "and two 19" automatically folded)

Frenzel water heater next to the pilot seat with automatic water filling.

Driver's bedroom with heating and telephon for communication with the driver.

A fridge in the front of the bus.

Carpets in the central tunnel, at the last row of passenger seats and around the driver's seat

Carpets in the luggage space

Adaptation to mounting a ski box

8. Driver space:

Pneumatic driver's seat adapts to the driver's weight, with seat heating and seat back.

5 points, pneumatic driver seat backrest adjustment.

Electrically operated front and side left window blinds.

Document safe placed under the driver's seat.

9. Passenger space

Two-point seat belts

Mesh for the press placed on the back of the backrest

Luggage shelves located above the passenger seats

Individual lighting, air conditioning and ventilation

stop button for each passenger

Curtains at the side and rear windows

Two emergency exits in the roof with manual tilt function

Footrests next to passenger seats
