New Water pump HDD Submersible Dredge Pump SDP 200 Demo model

HDD Submersible Dredging Pump 200 demo model from 2017.

The dredging pump has been running for 8 hours only.

Technical information:

- Capacity max.[m/hr] 850

- Work pressure max.[bar] 4,5

- Pump shaft at speed[rpm] 950 Max.

- power at shaft[kW] 140

- Suction diameter[mm] 200

- Pressure diameter[mm] 200

- Spherical passage[mm] 110

- Blades[pcs] 3

- Impeller size[mm] 600

The HDD Submersible Dredge Pumps are the highest efficiency Submersible Dredges Pumps available on the market. These versatile Submersible Dredge Pumps are available with different dredge tools depending on the situation and material which need to be dredged.

The capacity range is from 450 to 4500 m3/hr.

The high efficiency is achieved by the following features:

Adjustable impeller offset to the front plate

Double curved impeller blades

Compensation blades outside the impeller

Helix delivery pipe output

Operational areas:

Mineral Mining

River and Harbor Maintenance

Cleaning Hopper Barges

Land Reclamation

Dredging the Reservoirs from Hydroelectric Dams

www.bigdredging.com

More information

CE mark: yes

Serial number: 1
